Electrical specifications

Frequency range (MHz)

806-960/1710-2500

Polarization

Vertical

Gain(dBi)

4月7日

Half-power beam width(°)

Hor:120/80  Ver:100/65

Front-to-back ratio(dB)

≥12

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

100

Lightning protection

DC Ground

Mechanical specifications

Connector

N-Female

Connector position

Bottom

Diameter× Height(mm)

φ560×600

Packing size(mm)

590×590 ×630

Antenna weight(kg)

3.6

Packing weight(kg)

4.2

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

60

Reflector material

Aluninium

Radome material

Fiberglass

Radome color

Ivory-white

Operating temperature(℃)

-40～70

Mechanical tilt (°)

0～10
