Electrical specifications

Frequency range (MHz)

806-960/1710-2500

Polarization

±45°

Gain(dBi)

9月11日

Electrical downtilt(°)

Hor:65±6 Ver:60±5 Ver:35±5

Front-to-back ratio(dB)

≥25

Isolation (dB)

≥28

Intermodulation(dBm)

50

Impedance(Ω)

＜-97dBm (2*2W)

VSWR

≤1.5

Maximum input power(W)

100

Lightning protection

DC Ground

Mechanical specifications

Connector

2×N-Female

Connector position

Bottom

Size(mm)

530×290×135

Packing size(mm)

670×335×240

Antenna weight(kg)

5.5

Packing weight(kg)

6.8

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Aluminium

Radome material

PVC

Radome color

Grayish White

Operating temperature(℃)

-40～55

Mounting hardware(mm)

Φ80～φ114
