Electrical specifications

Frequency range (MHz)

824-960/1710-2500

Polarization

Vertical

Gain(dBi)

7月10日

Half-power beam width(°)

Hor:90/100  Ver:75/90

Front-to-back ratio(dB)

≥25

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

200

Lightning protection

DC Ground

Mechanical specifications

Connector

female

Connector position

Bottom

Size(mm)

765×550×320

Packing size(mm)

780×580 ×350

Antenna weight(kg)(Antenna weight)

0.5

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

60

Reflector material

Aluninium

Radome material

Fiberglass

Radome color

Gray

Operating temperature(℃)

-40～60
