Electrical specifications

Frequency range (MHz)

824-960

Polarization

±45°

Gain(dBi)

15

Electrical downtilt(°)

0～14

Half-power beam width(°)

Hor: 65±5  Ver: 15±3

Front-to-back ratio(dB)

≥25

Isolation(dB)

≥25

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

200

Lightning protection

DC Ground

Mechanical specifications

Connector

2×7/16 DIN female

Connector position

Bottom

Size(mm)

1700×950×600

Packing size(mm)

1730×980 ×630

Antenna weight(kg)(Antenna weight)

6.8

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Aluninium

Radome material

UPVC

Radome color

White

Operating temperature(℃)

-40～55
