Electrical specifications

Frequency Range (MHz)

902-928

Polarization

Vertical

Gain(dBi)

8

Half-power Beam width(°)

Hor:65  Ver:65

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

50

Lightning protection

DC Ground

Mechanical specifications

Connector

N-female

Connector position

Botton

Size(mm)

220×220×110

Packing Size(mm)

230×230×120

Antenna weight(kg)

0.5

Pcking weight(kg)

0.58

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector  material

Aluminum

Radome material

ABS

Radome color

White

Operating temperature(℃)

-40～55
