Electrical specifications

Frequency Range (MHz)

866±15

Polarization

Circular

Gain(dBi)

8

Half-power Beam width(°)

Hor:65  Ver:65

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

50

Lightning protection

DC Ground

Mechanical specifications

Connector

SMA-female

Connector position

Botton

Size(mm)

320×200×110

Packing Size(mm)

330×210×120

Antenna weight(kg)

0.58

Pcking weight(kg)

0.62

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

60

Reflector  material

Aluminum

Radome material

ABS

Radome color

White

Operating temperature(℃)

-40～70
