Electrical specifications

Frequency range (MHz)

902-928/866±15

Polarization

Horizontal

Gain(dBi)

12

Half-power beam width(°)

Hor:45  Ver:45

Front-to-back ratio(dB)

≥23

Impedance(Ω)

50

VSWR

≤1.4

Maximum input power(W)

50

Lightning protection

DC Ground

Mechanical specifications

Connector

N-female

Connector position

Bottom

Size(mm)

400×400×35

Packing size(mm)

/

Antenna weight(kg)

1.9

Packing weight(kg)

10

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Copper

Radome material

ABS

Radome color

White

Operating temperature(℃)

-40～55

Mounting hardware(mm)

φ40～φ70

Mechanical tilt(°)

±10
