Electrical specifications

Frequency range (MHz)

2400-2500

5150-5850

Polarization

2×Vertical +1×Horizontal

2×Vertical +1×Horizontal

Gain(dBi)

11±0.5

11±1

Half-power beam width(°)

Hor:32±3  Ver:60±3

Hor:32±6  Ver:60±8

Isolation (dB)

≥28

≥25

Front-to-back ratio (dB)

≥22

Impedance(Ω)

50

VSWR

≤1.5

≤1.8

Maximum input power(W)

100

Lightning protection

DC Ground

Mechanical specifications

Connector

6×N-Female

Connector position

Bottoml

Size(mm)

420×240×35

Packing size(mm)

460×260×50

Antenna weight(kg)

1.86

Packing weight(kg)

2.2

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Aluminum

Radome material

ABS

Radome color

White

Operating temperature(℃)

-40～55

Mounting hardware(mm)

φ40～φ50

Mechanical tilt(°)

±10
