Electrical specifications

Frequency range (MHz)

2400-2500

5150-5850

Polarization

6×Vertical

Gain(dBi)

8±0.5

10±1

Half-power beam width(°)

Hor:360  Ver:12

Hor:360 Ver:8

Un-roundness(dB)

±2

Isolation(dB)

≥20

Impedance(Ω)

50

VSWR

≤1.5

≤1.8

Maximum input power(W)

100

Lightning protection

DC Ground

Mechanical specifications

Connector

6×N-Female

Connector position

Bottom

Size(mm)

φ160×650

Packing size(mm)

750×200×200

Antenna weight(kg)

3.02

Packing weight(kg)

3.59

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Al/Cu

Radome material

U  PVC

Radome color

White

Operating temperature(℃)

-40～55

Mounting hardware(mm)

φ50～φ80
