Electrical specifications

Frequency range (MHz)

5150-5850

Polarization

Horizontal+Vertical

Gain(dBi)

23±1

Half-power beam width(°)

Hor:10±3  Ver:9±3

Front-to-back ratio(dB)

≥23

Isolation(dB)

≥25

Impedance(Ω)

50

VSWR

≤2.0

Maximum input power(W)

50

Lightning protection

DC Ground

Mechanical specifications

Connector

2×N-female

Connector position

Bottom

Size(mm)

400×400×40

Packing size(mm)

/

Antenna weight(kg)

1.7

Packing weight(kg)

/

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Aluminium

Radome material

ABS

Radome color

White

Operating temperature(℃)

-40～55

Mounting hardware(mm)

φ40～φ50
