Electrical specifications

Frequency range (MHz)

1710-1990

Polarization

Vertical

Gain(dBi)

11

Half-power beam width(°)

Hor:360  Ver:8±2

Un-roundness (dB)

±2

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

200

Lightning protection

DC Ground

Mechanical specifications

Connector

N-female/DIN-female

Connector position

Bottom

Size(mm)

Φ60×1900

Packing size(mm)

/

Antenna weight(kg)

3

Packing weight(kg)

3.5

Wind loading area(㎡)

≤0.2

Rated wind velocity(m/s)

36.9

Reflector material

Copper

Radome material

Fiberglass

Radome color

Grayish White

Operating temperature(℃)

-40～70

Mounting hardware(mm)

Φ50～φ70
