Electrical specifications

Frequency range (MHz)

1920-2170

Polarization

Vertical

Gain(dBi)

3

Half-power beam width(°)

Hor:360 Ver:60

Impedance(Ω)

50

VSWR

≤1.5

Maximum input power(W)

30

Lightning protection

DC Ground

Mechanical specifications

Connector

SMA-Male

Connector position

With cable

Size(mm)

φ30×222

Antenna weight(kg)

0.21

Wind loading area(㎡)

0.2

Rated wind velocity(m/s)

60

Reflector material

Steel

Radome material

ABS

Radome color

Black

Operating temperature(℃)

-40～70
